Specifications:

• Product Number: TEF1110P-8-63W

• Network standards:
  • IEEE 802.3/3u/3x
  • IEEE 802.3af/at

• LED Indicator
  • 10* Link/Ack LED indicators

  • 1 * Power LED indicator

• Interfaces
  • 8 * 10/100 Base-TX Ethernet ports (Data/Power)

  • 2 * 10/100 Base-TX Ethernet ports (Data)

• Transmission media: Recommended: CAT5/5e UTP or better

• Dimension: 177.5mmx104.0mmx26.0mm

• Level of protection
  • Lightning protection for ports: 6KV

  • Lightning protection for power: 4KV

  • ESD:

    • Air discharge: ±10kV

    • Contact discharge: ±8kV

• Forwarding mode: Store-and-forward

• Switch capacity: 1.6 Gbps

• Packet forwarding rate: 1.48Mpps

• Buffer: 448K

• MAC address table: 1K

• PoE budget
  • Single port: AF: 15.4W, AT: 30W

  • Whole device: 58W

• Input voltage
  • 100－240V AC 50/60Hz

  • 51V /1.25A DC（Power Adapter ）

• Mounting
  • Desktop mounting: support

  • Wall mounting: support

  • Rack mounting: non-support

• Environment
  • Operating Temperature: 0℃~45℃

  • Storage Temperature: -40℃~70℃

  • Operating Humidity: 10%~90% non-condensing

  • Storage Humidity: 5%~90% non-condensing

• Certification
  • FCC
  • CE
  • RoHS

• Funtions

  •  Default Mode: If Default mode is enabled, the device works as a general switch and all ports support 10/100Mbps auto-negotiation.

  • Extend Mode: VLAN isolation is enabled. Port 1-8 will be isolated respectively (10/100Mbps auto-negotiation), but can communicate with the Uplink port. And the delivery distance of powering and network data is up to 250m (10Mbps).
